1500

Housing No.
Shaft
Dimensions mm
Weight (kg)
Bearing No.
Adapter Sleeve
d1
a
m
h
c
L
b
D
g
f1
f2
d2
d3
v
u
h12
h8
h12
H12
h12
h12
1504
17
128
98
31
14
50
34
47
18
2.5
3.2
18.5
28
16
12
0.67
1204K
2204K
H204
H304
1505
20
134
104
34
15
57
37
52
18
2.5
3.5
21.5
31
16
12
0.78
1205K
2205K
H205
H305
1506
25
150
118
39
15
60
40
62
20
2.8
3.5
26.5
38
18
12
1
1206K
2206K
H206
H306
1507
30
177
140
45
17
69
44
72
23
3.2
4
31.5
43
20
14
1.6
1207K
2207K
H207
H307
1508
35
190
150
48
18
75
53
80
23
3.2
4
36.5
48
22
14
1.95
1208K
2208K
H208
H308
1509
40
195
157
52
19
77
53
85
23
3.5
4
41.5
53
22
14
2.2
1209K
2209K
H209
H309
1510
45
206
165
54
21
83
56
90
23
3.5
4
46.5
58
22
14
2.8
1210K
2210K
H210
H310
1511
50
229
183
62
22
90
67
100
25
3.5
4
51.5
67
25
18
3.7
1211K
2211K
H211
H311
1512
55
249
205
69
22
92
69
110
28
3.5
4
56.5
72
25
18
4.8
1212K
2212K
H212
H312
1513
60
266
217
73
26
94
73
120
31
4.5
5
62
77
25
18
5.5
1213K
2213K
H213
H313
1515
65
280
225
78
26
95
75
130
31
4.5
5
67
82
26
18
6
1215K
2215K
H215
H315
1516
70
300
240
86
26
110
78
140
33
5
6
72
89
28
18
8.2
1216K
2216K
H216
H316
1517
75
320
260
92
28
125
88
150
36
6
6.5
77
94
30
18
10
1217K
2217K
H217
H317
1518
80
360
290
100
30
130
90
160
40
6
6.5
82
99
40
22
13
1218K
2218K
H218
H318
