Double-row tapered roller bearings

Principal Dimensions (mm)基本尺寸						Basic Load Ratings (kN) 基本额定负荷		Limiting Speeds (r/min) 极限转速		Bearing Numbers轴承代号	Weight (kg)重量
d	D	B2	C	r min	r1 min	Cr	Cor	Grease	Oil
d	D	B2	C	r min	r1 min	Cr	Cor	Grease	Oil
40	80	45	37.5	1.5	0.6	109	140	3700	5100	HR40KBE42+L	0.97
45	85	47	37.5	1.5	0.6	117	159	3400	4700	HR45KBE42+L	1.08
45	85	55	43.5	1.5	0.6	143	204	3400	4700	HR45KBE52X+L	1.31
50	90	48	38.5	1.5	0.6	131	183	3200	4400	HR50KBE042+L	1.2
50	90	49	39.5	1.5	0.6	131	183	3200	4400	HR50KBE42+L	1.22
50	90	55	43.5	1.5	0.6	150	218	3200	4400	HR50KBE52X+L	1.39
50	110	64	51.5	2.5	0.6	224	297	2700	3700	HR50KBE043+L	2.77
55	100	51	41.5	2	0.6	162	226	2900	3900	HR55KBE042+L	1.59
55	100	52	42.5	2	0.6	162	226	2900	3900	HR55KBE1003+L	1.63
55	100	60	48.5	2	0.6	188	274	2900	3900	HR55KBE52X+L	1.88
55	120	70	57	2.5	0.6	256	342	2500	3400	HR55KBE43+L	3.52
60	110	53	43.5	2	0.6	178	246	2700	3600	HR60KBE042+L	2.03
60	110	66	54.5	2	0.6	225	335	2700	3600	HR60KBE52X+L	2.52
60	130	74	59	3	1	298	405	2300	3200	HR60KBE43+L	4.4
65	120	56	46.5	2	0.6	210	300	2400	3200	HR65KBE042+L	2.58
65	120	57	47.5	2	0.6	210	300	2400	3200	HR65KBE1202+L	2.61
65	120	73	61.5	2	0.6	269	405	2400	3300	HR65KBE52X+L	3.35
65	140	79	63	3	1	340	465	2100	2900	HR65KBE43+L	5.42
70	125	57	46.5	2	0.6	227	325	2300	3100	HR70KBE042+L	2.79
70	125	59	48.5	2	0.6	227	325	2300	3100	HR70KBE42+L	2.85
70	125	74	61.5	2	0.6	270	410	2300	3100	HR70KBE52X+L	3.58
70	150	83	67	3	1	390	535	2000	2700	HR70KBE43+L	6.45
75	130	62	51.5	2	0.6	245	365	2200	3000	HR75KBE42+L	3.15
75	130	74	61.5	2	0.6	283	440	2200	3000	HR75KBE52X+L	3.73
75	160	87	69	3	1	435	600	1900	2500	HR75KBE043+L	7.66
80	140	61	49	2.5	0.6	269	390	2000	2800	HR80KBE042+L	3.7
80	140	64	51.5	2.5	0.6	269	390	2000	2800	HR80KBE42+L	3.7
80	140	78	63.5	2.5	0.6	330	505	2000	2800	HR80KBE52X+L	4.59
80	170	92	73	3	1	475	655	1700	2400	HR80KBE043+L	9.02
85	150	70	57	2.5	0.6	315	465	1900	2600	HR85KBE42+L	4.69
85	150	86	69	2.5	0.6	360	555	1900	2600	HR85KBE52X+L	5.7
85	180	98	77	4	1	530	745	1600	2200	HR85KBE043+L	10.8
90	160	71	58	2.5	0.6	345	510	1800	2400	HR90KBE042+L	5.53
90	160	74	61	2.5	0.6	345	510	1800	2400	HR90KBE42+L	5.71
90	160	94	77	2.5	0.6	440	700	1800	2400	HR90KBE52X+L	7.26
90	190	102	81	4	1	595	845	1600	2100	HR90KBE043+L	12.7
90	190	144	115	4	1	770	1180	1600	2200	HR90KBE1901+L	17.9
95	170	78	63	3	1	385	570	1700	2300	HR95KBE42+L	6.75
95	170	100	83	3	1	495	800	1700	2300	HR95KBE52+L	8.6
95	200	108	85	4	1	640	910	1500	2000	HR95KBE43+L	14.7
100	165	52	46	2.5	0.6	222	340	1700	2300	100KBE31+L	4.04
100	180	81	64	3	1	435	665	1600	2200	HR100KBE1805+L	8.16
100	180	81	65	3	1	435	665	1600	2200	HR100KBE042+L	8.13
100	180	82	66	3	1	435	665	1600	2200	HR100KBE1801+L	8.22
100	180	83	67	3	1	435	665	1600	2200	HR100KBE42+L	8.7
100	180	105	85	3	1	555	905	1600	2200	HR100KBE1802+L	10.6
100	180	107	87	3	1	555	905	1600	2200	HR100KBE52X+L	10.7
100	180	110	90	3	1	555	905	1600	2200	HR100KBE1804+L	11
100	215	112	87	4	1	725	1050	1400	1900	HR100KBE043+L	18.1
105	190	88	70	3	1	480	735	1500	2000	HR105KBE42X+L	9.76
105	190	117	96	3	1	620	1020	1500	2000	HR105KBE1902+L	13.4
105	190	115	95	3	1	620	1020	1500	2000	HR105KBE52+L	13.1
105	225	116	91	4	1	780	1130	1300	1800	HR105KBE043+L	20.4
110	180	56	50	2.5	0.6	264	400	1500	2000	110KBE31+L	5.11
110	180	70	56	2.5	0.6	340	555	1500	2000	110KBE031+L	6.33
110	180	125	100	2.5	0.6	550	1060	1500	2100	110KBE1802+L	11.4
110	200	90	72	3	1	540	840	1400	1900	HR110KBE42+L	11.2
110	200	92	74	3	1	540	840	1400	1900	HR110KBE42X+L	11.5
110	200	120	100	3	1	685	1130	1400	1900	HR110KBE2001+L	15.4
110	200	121	101	3	1	685	1130	1400	1900	HR110KBE52X+L	15.2
110	240	118	93	4	1.5	830	1190	1200	1700	HR110KBE043+L	23.6
120	180	46	41	2.5	0.6	184	296	1500	2000	120KBE30+L	3.75
120	180	58	46	2.5	0.6	260	450	1500	2000	120KBE030+L	4.64
120	200	62	55	2.5	0.6	310	500	1400	1800	120KBE31+L	7.35
120	200	78	62	2.5	0.6	415	690	1400	1900	120KBE031+L	8.97
120	200	100	84	2.5	0.6	515	885	1400	1800	120KBE2001+L	11.3
120	215	97	78	3	1	575	900	1300	1800	HR120KBE42X+L	13.7
120	215	132	109	3	1	750	1270	1300	1800	HR120KBE52X+L	18.8
120	260	128	101	4	1	915	1310	1100	1500	HR120KBE43+L	29.4
120	260	188	145	4	1	1320	2110	1100	1500	HR120KBE2601+L	44.6
125	210	110	88	4	1	560	1030	1300	1800	125KBE2101+L	14.5
130	230	98	78.5	4	1	640	1010	1200	1600	HR130KBE42+L	15.8
130	230	100	80.5	4	1	640	1010	1200	1600	HR130KBE2301+L	15.9
130	280	137	107.5	5	1.5	940	1350	1000	1400	130KBE43+L	35
130	230	145	115	4	1	905	1580	1200	1700	HR130KBE2302+L	24.1
130	230	145	117.5	4	1	905	1580	1200	1700	HR130KBE52+L	23.8
130	230	150	120	4	1	905	1580	1200	1700	HR130KBE2303+L	24.2
140	210	53	47	2.5	0.6	280	495	1200	1700	140KBE30+L	6.02
140	210	106	94	2.5	0.6	555	1200	1300	1700	140KBE030+L	7.02
140	210	66	53	2.5	1	305	530	1200	1700	140KBE2101+L	12.3
140	225	68	61	3	1	400	630	1200	1600	140KBE31+L	9.31
140	225	84	68	3	1	490	850	1200	1600	140KBE031+L	11.6
140	225	85	68	3	1	490	850	1200	1600	140KBE2201+L	11.7
140	230	120	94	3	1	685	1270	1200	1600	140KBE2301+L	17.6
140	230	140	110	3	1	820	1550	1200	1600	140KBE2302+L	20.7
140	240	132	106	4	1.5	685	1360	1100	1500	140KBE2401+L	22.7
140	250	102	82.5	4	1	670	1030	1100	1500	HR140KBE42+L	18.9
140	250	153	125.5	4	1	1040	1830	1100	1500	HR140KBE52X+L	29.6
140	300	145	115.5	5	1.5	1030	1480	1000	1300	140KBE43+L	42.6
150	225	56	50	3	1	300	545	1200	1600	150KBE30+L	7.41
150	225	70	56	3	1	395	685	1200	1600	150KBE030+L	8.7
150	250	80	71	3	1	510	810	1100	1400	150KBE31+L	14.2
150	250	100	80	3	1	630	1090	1100	1400	150KBE031+L	17.8
150	250	115	95	3	1	745	1320	1100	1500	150KBE2502+L	20.9
150	260	150	115	4	1	815	1520	1100	1400	150KBE2601+L	30
150	270	109	87	4	1	830	1330	1000	1400	HR150KBE42+L	24.3
150	270	164	130	4	1	1210	2150	1000	1400	HR150KBE52X+L	37.3
150	270	174	140	4	1	1210	2150	1000	1400	HR150KBE2701+L	39.7
150	320	154	120	5	1.5	1420	2130	900	1200	HR150KBE43+L	53.4
160	240	60	53	3	1	355	580	1100	1500	160KBE30+L	8.56
160	240	75	60	3	1	395	710	1100	1500	160KBE030+L	10.5
160	240	110	90	3	1	650	1290	1100	1500	160KBE2401+L	16.2
160	270	86	76	3	1	540	885	1000	1300	160KBE31+L	18.6
160	270	108	86	3	1	775	1380	1000	1300	160KBE031+L	23.1
160	270	140	120	3	1	990	1220	1000	1300	160KBE2701+L	30.6
160	280	150	125	4	1	1100	2020	1000	1300	160KBE2801+L	35.9
160	290	115	91	4	1	800	1220	900	1300	160KBE42+L	28.2
160	290	178	144	4	1	1360	2440	1000	1300	HR160KBE52X+L	47.3
160	340	160	126	5	1.5	1310	1920	800	1100	160KBE43+L	60.4
165	290	150	125	4	1	1140	2130	900	1300	165KBE2901+L	39.5
170	250	85	65	3	1	435	845	1000	1400	170KBE2501+L	12.3
170	260	67	60	3	1	400	700	1000	1300	170KBE30+L	11.8
170	260	84	67	3	1	575	1030	1000	1300	170KBE030+L	14.4
170	280	88	78	3	1	630	1040	900	1300	170KBE31+L	19.7
170	280	110	88	3	1	820	1450	900	1300	170KBE031+L	24.2
170	280	150	130	3	1	1110	2160	1000	1300	170KBE2802+L	34.6
170	310	192	152	5	1.5	1590	2910	900	1200	HR170KBE52X+L	57.3
180	280	74	66	3	1	455	810	900	1300	180KBE30+L	15.4
180	280	93	74	3	1	655	1220	900	1200	180KBE030+L	14.4
180	300	96	85	4	1.5	725	1210	900	1200	180KBE31+L	24.8
180	300	120	96	4	1.5	940	1690	900	1200	180KBE031+L	31.1
180	320	127	99	5	1.5	895	1390	800	1200	180KBE42+L	36.5
180	320	192	152	5	1.5	1640	3050	900	1200	HR180KBE52X+L	59.2
180	340	180	140	5	1.5	1410	2510	800	1100	180KBE3401+L	68.1
190	290	75	67	3	1	490	845	900	1200	190KBE30+L	16.2
190	290	94	75	3	1	670	1230	900	1200	190KBE030+L	20.1
190	320	104	92	4	1.5	800	1380	800	1100	190KBE31+L	30.9
190	320	130	104	4	1.5	1070	1960	800	1100	190KBE031+L	39
190	340	133	105	5	1.5	990	1580	800	1100	190KBE42+L	43.9
190	340	204	160	5	1.5	1910	3550	800	1100	HR190KBE52X+L	70.8
200	310	152	123	3	1	1300	2740	800	1100	HR200KBE3101+L	40.1
200	320	146	110	5	1.5	990	2120	800	1100	200KBE3201+L	41.6
200	330	180	140	5	1.5	1390	2730	800	1100	200KBE3301+L	54.4
200	340	112	100	4	1.5	940	1670	800	1000	200KBE31+L	38.8
200	340	140	112	4	1.5	1260	2250	800	1000	200KBE031+L	47
200	360	142	110	5	1.5	1100	1780	700	1000	200KBE42+L	52.6
200	360	218	174	5	1.5	2070	3850	800	1000	HR200KBE52+L	88.3
206	283	102	83	4	1.5	580	1430	900	1200	206KBE2801+L	18.1
210	355	116	103	4	1.5	905	1520	700	1000	210KBE31+L	41.7
220	300	110	88	3	1	730	1710	800	1100	220KBE3001+L	21.2
220	340	90	80	4	1.5	695	1280	700	1000	220KBE30+L	27.9
220	340	113	90	4	1.5	920	1830	700	1000	220KBE030+L	34.7
220	370	120	107	5	1.5	1110	1940	700	1000	220KBE31+L	48.3
220	370	150	120	5	1.5	1460	2760	700	1000	220KBE031+L	60.2
220	400	158	122	5	1.5	1390	2300	600	900	220KBE42+L	74.2
240	360	92	82	4	1.5	780	1490	700	900	240KBE30+L	30.1
240	360	115	92	4	1.5	1020	2040	700	900	240KBE030+L	37.3
240	400	128	114	5	1.5	1180	2190	600	900	240KBE31+L	60
240	400	160	128	5	1.5	1620	3050	600	900	240KBE031+L	73.6
240	400	209	168	5	1.5	2220	4450	600	900	240KBE4003+L	96.4
250	380	98	87	4	1	795	1460	600	900	250KBE3801+L	35.5
260	400	104	92	5	1.5	895	1670	600	800	260KBE30+L	43.4
260	400	130	104	5	1.5	1210	2460	600	800	260KBE030+L	54.1
260	440	144	128	5	1.5	1540	2760	600	800	260KBE31+L	82.5
260	440	172	145	5	1.5	1870	3500	600	800	260KBE4401+L	98.1
260	440	180	144	5	1.5	2110	4150	600	800	260KBE031+L	104
