SD500-SD600

Housing No.
Shaft dia
Dimensions(mm)
Housing
Bearing No.
Adapter
Locating Ring
Housing
d1(mm)
Wt
Sleeve
No.
D
a
b
c
g
h
L
W
m
n
u
v
s
d2
d3
f1
f2
(kg)
Number
QTY
H8
H12
h12
H12
H12
H13
SD534
150
310
620
230
60
106
180
270
360
510
140
36
52
M30
153
183
10
13.8
92
22234K
H3134
SR310x10
2
SD534
SD536
160
320
650
240
60
106
190
280
380
540
150
36
52
M30
163
193
10
13.8
105
22236K
H3136
SR320x10
2
SD536
SD538
170
340
700
260
65
112
200
290
400
570
160
36
55
M30
173
203
10
13.8
125
22238K
H3138
SR340x10
2
SD538
SD540
180
360
740
270
65
118
210
300
420
610
170
36
55
M30
183
213
10
13.8
140
22240K
H3140
SR360x10
2
SD540
SD544
200
400
820
300
70
128
240
330
475
680
190
43
62
M36
203
240
11
15.7
200
22244K
H3144
SR400x10
2
SD544
SD548
220
440
880
310
85
140
260
340
515
740
200
43
62
M36
223
260
11
15.7
230
22248K
H3148
SR440x10
2
SD548
SD552
240
480
940
340
85
150
280
370
560
790
210
43
62
M36
243
286
12
17.4
300
22252K
H3152
SR480x10
2
SD552
SD556
260
500
990
370
100
150
300
390
590
830
230
50
70
M42
263
306
12
17.4
350
22256K
H3156
SR500x10
2
SD556
SD560
280
540
1060
390
100
160
325
410
640
890
250
50
70
M42
283
332
13
19.1
450
22260K
H3160
SR540x10
2
SD560
SD564
300
580
1110
420
110
170
355
440
690
930
270
58
77
M48
303
352
13
19.1
550
22264K
H3164
SR580x10
2
SD564
